1. Automated Job Set-Up and Job Memory
2. Remote controller and 3 sets of HMI Screen for operation
3. Each Feeder belts driven by servo motor independently, pneumatic lifter side gates and feeding knife for easy operation
4. All tools are lifted and positioned without dismantling, fast change-over time, improve efficiency
5. No need to remove 4&6 corner back hooks when the back folding system is not in use
Functional Overview
1. Automated Job Set-Up and Job Memory
2. Remote controller and 3 sets of HMI Screen for operation
3. Each Feeder belts driven by servo motor independently, pneumatic lifter side gates and feeding knife for easy operation
4. All tools are lifted and positioned without dismantling, fast change-over time, improve efficiency
5. No need to remove 4&6 corner back hooks when the back folding system is not in use
Technical data
|
Processed Materials |
YJZ-900F |
YJZ-1100F |
YJZ-1200F |
|
Cardboard |
200~800 gsm |
||
|
Corrugated Flute Type |
E-flute and F-flute |
||
|
Speed |
Max. 400 m/min |
||
|
Dimensions & Weight |
|||
|
Length |
16 m |
16 m |
16m |
|
Width |
1.6 m |
1.8m |
2.0m |
|
Height |
1.85 m |
1.85 m |
1.85m |
|
Net Weight |
8 Ton |
8.5 Ton |
9Ton |
|
Installation |
|||
|
Electrical Connected Load |
50 KW |
||
|
Power Supply |
380 Volts 3 Phase 50 Hz |
||
|
Compressed Air |
6 bar |
||
|
Air Compressor Capacity |
10 m³/h |
||
|
Air Tank Capacity |
60 L |
||
